Circular Vibrating Screen is a new type of vibrating screen with multiple layers and high efficiency developed by us. The machine adopts a cylindrical eccentric shaft exciter and an eccentric block to adjust the amplitude. The material screen has a long flow line and a variety of screening specifications. It has reliable structure, strong excitation force, high screening efficiency, low vibration noise, strong durability and convenient maintenance. safe in use and other characteristics, it is widely used in product grading operations in mining, building materials, chemical and other industries.

Circular Vibrating Screen is a screening equipment with a three-axis block eccentric exciter as the excitation source, the rubber support spring as the elastic element, and the screen box exciter as the movable part. The three shafts of the vibrator are equipped with counterweight blocks with the same mass and equal radius. The power of the vibrating screen is transmitted by the motor through the belt to the driving shaft, and then driven by a power gear with a speed ratio of 1, so that the three shafts rotate at the same speed, thereby generating an exciting force and making the screen box perform continuous eccentric circular motion. Under this power, the material continuously throws down the horizontal screen surface in the circumferential direction, and moves forward while throwing up the loose layers, completing the process of particle size screening and conveying over and over again.
