Stone Production Line is Suitable for Water and Electricity, Building Material, Highway and Other Industries, Can Be Used for Hard Limestone, Granite, Basalt, Cobble, Slag of a Variety of Materials.

Feeding Size: 0-1200mm

Output aggregates sizes: 5mm;10mm;20mm;30mm;1/4";1";2";etc.

Processing Capacity: 20-1000t/h

Applied Materials: Granite, Basalt, Limestone, River stone; Feldspar; Andesite, Phonolite, Dolomite, Barite, Construction Waste; iron tailings, etc.

Details Overview: stone production line is suitable for water and electricity, building material, highway and other industries, can be used for hard limestone, granite, basalt.

Equipment Configuration of stone crushing line:

Medium and Soft rock and stone:
Vibrating feeder + Jaw crusher + Impact crusher + Circular vibrating screen + Several belt conveyor;

Medium and hard rock and stone:
Vibrating feeder +Jaw crusher + Cone crusher + Circular vibrating screen + Several belt conveyor;
Customer can select dust remove machine or not according to local environment protect requires

Process of stone crushing line:

Big materials are fed to the jaw crusher evenly and gradually by vibrating feeder through a hopper for primary crushing. After first crush, the material will transferred to impact crusher (or Cone crusher) by belt conveyor for secondary crush; the crushed materials will then transferred to vibrating screen for separating. This step is very important in stone crushing lines. After separating, the parts that can meet standard will be transferred away as final products, while the other parts will be returned to impact crusher (or Cone crusher), thus forming a closed circuit. Size of final products can be combined and graded according to customer’s specific requirement. We can also equip dust catcher system to protect environment.
